Electronic Parameters
Connection standard | ISO5211 F03、F05 |
Output axis specification | Female octagonal 9*9 or 11*11 |
Maximum working pressure | 1.0MPa |
Rated voltage | AC24V , DC12-24V, AC110-230V |
Wiring diagram | CR202; CR303;CR306;CR502;CR703;CR706 (Optional) |
Life time | 70000 times（testing pressure is 0.4MPa, medium is water） |
Actuator material | Engineering Plastics PPO |
Torque force | 15 N.m |
Cable Length | 0.5m |
Environment temperature | -15～60 centigrade |
Liquid temperature | 2～90 centigrade |
Manual operation | Yes |
Open/close indicator | Yes |
Protection class | IP67 |
Company quality management | ISO 9001:2015 |
